Clean Room Air showers
Mycron Air Tech presents its Air showers are made of MS/GI powder coated and stainless steel 304 / 316 grades with international quality standard components. Air showers are specialized enclosed antechambers which are incorporated as entryways of clean rooms and other controlled environments to reduce particle contamination. Air showers utilize high-pressure, HEPA filtered air to remove dust, fibrous lint and other contaminants from personnel or object surfaces. The forceful “cleansing” of surfaces prior to entering clean environments reduces the number of airborne particulates introduced.
Air showers are generally constructed from clean room compatible steel or plastic materials and feature electronically powered blowers, filters and high-pressure jet nozzles. The latter being incorporated into the walls and ceiling of the chamber. Air at velocities of 3,000 to 7,000 feet-per-minute (FPM), continuously streams from the jet nozzles for 20-40 seconds effectively removing loose particulate matter. Personnel inside the enclosure will lift their arms and turn their bodies for uniform exposure to the air streams. A procedure usually specified in protocol. Air currents from the jets create shearing and flapping forces which lift and remove contaminants from both flat surfaces and the creases of garments. HEPA filtration within the air shower is capable of removing 99.97% of particles greater than 0.3µm diameter.
Sl.No | Features | Specifications |
1 | Available Sizes w.r.t Working Area in mm (LxBxH) | 900x1000x2100 (1 meter), 900x2000x2100(2 meter) up to 10 meters |
2 | Material of Construction | MS/GI Power coated, SS 304/316 |
3 | MOC of Working Area | MS/GI Power coated, SS 304/317 |
4 | HEPA Filter w.r.t Working Area in mm (LxBxH) | 0.3 µ Mini Plate 610x915x75 |
5 | Pre Filter | 10 µ 800x400x50 |
6 | Motor & Blower | Dynamically balanced Motor with Aluminum/PVC Blower |
7 | Nozzle | Yes, Rotatable type |
8 | No of Nozzles | 14 – 17 per meter |
9 | Shower duration | 0-60 secs Adjustable |
10 | Protections | Electro Magnet Inter locking for both doors, Emergency Exit push button, Separate Thermal relay for Motor protection, |
11 | Door | MS/GI Power coated, SS 304/317 with Static Handle and Door closer |
12 | Illumination | Yes, LED |
13 | Power Required | Three Phase 415V/50 Hz |
14 | Total Power Consumption | 5KW |
15 | Noise level | 75 db +/- 5 db |
16 | Vibration Level | < 2.5 µm (0.000025m) |
