Men and Material Entry Air showers
Mycron Air Tech presents its Air showers are made of GI powder coated and stainless steel 304 grades with international quality standard components. Air showers are specialized enclosed antechambers which are incorporated as entry ways of clean rooms and other controlled environments to reduce particle contamination. Air showers utilize high-pressure, HEPA filtered air to remove dust, fibrous lint and other contaminants from personnel or object surfaces.
Get In Touch
Mycron Provides the best laboratory experience
Air showers are generally constructed from clean room compatible steel materials and feature electronically powered blowers, filters and high-pressure jet nozzles. Air at velocities of 20 m/s, continuously streams from the jet nozzles for 20-40 seconds effectively removing loose particulate matter. Personnel inside the enclosure will lift their arms and turn their bodies for uniform exposure to the air streams. A procedure usually specified in protocol. Air currents from the jets create shearing and flapping forces which lift and remove contaminants from both flat surfaces and the creases of garments. HEPA filtration within the air shower is capable of removing 99.97% of particles greater than 0.3µm diameter.
Air Shower Types:
| Sl.No | Features | Specifications |
|---|---|---|
| 1 | Available Sizes for Working Area in mm (LxBxH) | 900x1000x2100 (1 meter), 900x2000x2100 (2 meter) up to 10 meters (Tunnel Type) |
| 2 | Material of Construction | GI Power coated, SS 304 |
| 3 | MOC of Working Area | GI Power coated, SS 304 |
| 4 | HEPA Filter | HEPA Filter having EU 14 rating with suitable size. Efficiency – 99.997% down to 0.3 Microns. |
| 5 | Pre Filter | EU 4 rating with suitable size. Efficiency – 90% down to 10 Microns |
| 6 | Motor & Blower | Dynamically balanced Motor with Aluminum impeller |
| 7 | Nozzle | Yes, Rotatable type |
| 8 | No of Nozzles | 14 – 17 per meter |
| 9 | Shower Duration | 0-60 secs Adjustable |
| 10 | Protections | Electro Magnet Inter locking for both doors, Emergency Exit push button, Separate Thermal relay for Motor protection |
| 11 | Door | GI Power coated, SS 304 with Static Handle and Door closer |
| 12 | Illumination | Yes, LED |
| 13 | Power Required | Three Phase 415V/50 Hz |
| 14 | Total Power Consumption | 3 to 15 KW |
| 15 | Noise level | 75 ± 5 db |
Air showers are generally constructed from clean room compatible steel materials and feature electronically powered blowers, filters and high-pressure jet nozzles. Air at velocities of 20 m/s, continuously streams from the jet nozzles for 20-40 seconds effectively removing loose particulate matter. Personnel inside the enclosure will lift their arms and turn their bodies for uniform exposure to the air streams. A procedure usually specified in protocol. Air currents from the jets create shearing and flapping forces which lift and remove contaminants from both flat surfaces and the creases of garments. HEPA filtration within the air shower is capable of removing 99.97% of particles greater than 0.3µm diameter.
